A thermoforming platform for plate mounted male molds
Experience is the key to every adjustable master mold base we make. Behind each of these mold bases, you’ll find years of tooling design experience and countless satisfied job shops.
Our mold base easily adjusts to job-specific lengths. Simply loosen two screws, slide the front clamp bar to the desired mold plate length, mount the mold plate, tighten the screws-and you’re ready for part forming.
“Master-full” features & benefits:
Rapid mold changeover
Front/rear sheet clamps pinch off and isolate hot plastic sheet, preventing distortion by holding sheets flat prior to plastic displacement by molds or plugs
Two 1 1/2″ NPT vacuum ports provide maximum air evacuation and guarantee sharp part production
Simple adjustability to required index length
Five gallon-per-minute coolant flow rate ensures maximum cooling through two independent water circuits reduces mold temperature recovery time and increases cycle rate.
Standard overall height 5.5″
Other custom sizes available on request, contact us for more information or a quote.
